IW-RS108-07
500W 1U single PSU 750W 1U redundant PSU 80 Plus Gold 80 Plus Platinum
Zur Erstellung einer Wunschliste bitte einloggen.
- Intel® Xeon Scalable & AMD EPYC family compliant
- Backplanes with Mini-SAS HD and OCuLink connectors
- Maximum supports U.2 NVMe SSDs x 8; 3.5″/2.5″ (15mm) trays x 4, and 2.5″ (7mm) trays x 4
- Flexible storage configuration of 3.5″ HDDs and 2.5″ SSDs (15mm, 7mm)
- Intensive airflow generated by easy-swap cooling fans x 6
- Full-height PCIe slot x 1 (via riser card)
- 80 Plus Gold Single PSU or 80 Plus® Platinum 1U redundant PSU(optional)
- Customized I/O shield backplate for specific motherboards with SGCC material
Dieser Artikel ist in diesen
Kategorien gelistet:
Detail-Informationen_
| Detailinformationen | 3.5"/2.5" (15mm) trays x 4, AMD EPYC family compliant, and 2.5" (7mm) trays x 4, Backplanes with Mini-SAS HD and OCuLink connectors, Flexible storage configuration of 3.5" HDDs and 2.5" SSDs (15mm, Intel® Xeon Scalable amp, Maximum supports U.2 NVMe SSDs x 8 |
|---|---|
| Serie | |
| Chassis Form Factor | Rackmount Chassis |
| Industry Standard | |
| Cases Size | |
| MB Form Factor | |
| External Drive Bays | |
| Internal Drive Bays | |
| Power Supply | 500W 1U single PSU, 750W 1U redundant PSU, 80 Plus Gold, 80 Plus Platinum |
| Indicators | |
| Front Control Panel | |
| Cooling Fans | 60 x 25mm PWM rear fan x 2 (optional), 80 x 25mm PWM front fan x 1, 21500RPM, 40 x 56mm PWM easy-swap fans x 6 |
| Expansion Slots | |
| Material | |
| Rail Kit | |
| Product Dimensions | |
| Packing Dimensions | |
| Weight | |
| Shipping Information | 20': 200pcs, 40': 440pcs, 40'HQ: 528pcs, Single packing with pallets: |
Packaging_
Product Dimensions
660 x 438 x 43.5 mm
Package dimensions
880 x 610 x 180mm
