| Dimensions |
660 × 438 × 43,5 cm |
| Power Supply |
500W 1U single PSU, 750W 1U redundant PSU, 80 Plus Gold, 80 Plus Platinum
|
| Product Dimensions |
660 x 438 x 43.5 mm
|
| Packing Dimensions |
880 x 610 x 180mm
|
| Cases Size |
1U Rackmount Chassis
|
| External Drive Bays |
8
|
| MB Form Factor |
CEB, EEB, ATX
|
| Chassis Indicator |
HDD LED, ID LED, LAN1/LAN2 LED, Power LED, system LED
|
| Chassis Front Control |
ID SW, NMI, Power on/off, reset
|
| Serie |
1U
|
| SUB - Serie |
NVME Storage Server
|
| Industry Standard |
EIA-RS310D
|
| Internal Drive Bays |
0
|
| Indicators |
HDD LED, ID LED, LAN1/LAN2 LED, Power LED, system LED
|
| Front Control Panel |
NMI, Reset, ID SW, Power on/off
|
| Cooling Fans |
60 x 25mm PWM rear fan x 2 (optional), 80 x 25mm PWM front fan x 1, 21500RPM, 40 x 56mm PWM easy-swap fans x 6
|
| Expansion Slots |
Full-height PCIe slot x 1 (via riser card)
|
| Material |
Material: SGCC, Thickness: 1.0mm
|
| Rail Kit |
Supports 28" tool-less ball-bearing slide rails
|
| Weight |
Gross weight: 11.92kg, Net weight: 8.5kg
|
| Shipping Information |
20': 200pcs, 40': 440pcs, 40'HQ: 528pcs, Single packing with pallets:
|
| Backplane Type-1 Specs |
Top Layer Backplane: OCuLink backplane Bottom Layer Backplane: Mini-SAS HD OCuLink backplane
|
| HDD / SSD Interface |
Top Layer Backplane: NVMe/SAS/SATA x 4 (2.5" 7mm) Bottom Layer Backplane: NVMe/SAS/SATA x 4 (3.5"/2.5" 15mm)
|
| Detailinformationen |
3.5"/2.5" (15mm) trays x 4, AMD EPYC family compliant, and 2.5" (7mm) trays x 4, Backplanes with Mini-SAS HD and OCuLink connectors, Flexible storage configuration of 3.5" HDDs and 2.5" SSDs (15mm, Intel® Xeon Scalable amp, Maximum supports U.2 NVMe SSDs x 8
|
| Chassis Form Factor |
Rackmount Chassis
|
